Floor Mounted Indoor Unit

Economy Mode
Minimum Heat Mode
Auto Changeover
Automatic air flow adjustment
Auto Restart/Reset
Dry Mode
Powerful Operation
Quiet Mode (Indoor Unit)
24 Hour Timer
Sleep Timer
Weekly Timer
Apple Catechin Filter (polyphenol ingredient from apples)
Cold Prevention
Ion Deodorizing Filter
Outdoor Unit Low Noise
Hydro Fin

KUBS1G

The Centauri Series Floor-Mounted Indoor Unit delivers high-efficiency heating and cooling in a compact, low-profile design engineered for flexible installation under a standard window. Dual upper and lower airflow outlets enable rapid, uniform space conditioning, while floor-level or low-wall mounting provides evenly distributed airflow with quiet operation for consistent, year-round comfort. The unit also includes a built-in refrigerant leak detection sensor for enhanced safety and reliability.

Size (kBTU/h): 9, 12, 15

Features

Ducted Technology

AIRSTAGE mini-splits are easy to install, require little or no ducting, and can provide comfort for any room or the entire home.

Year-Round Comfort

AIRSTAGE systems offer both heating and cooling to keep you comfortable year-round.

Energy Efficient

Save up to 30% on energy bills with AIRSTAGE H-Series systems. Take advantage of local rebates and save even more.

No Temperature Lockout!

Heating down to 5°F (-21°C) without sacrificing heating capacity at low outdoor temperatures

Specifications

Sound Level: As low as 22dB
SEER2: As high as 26 BTU/hW
HSPF2: As high as 11.3 BTU/hW
Energy Star: ESC & ESCC
Cooling Operating Range: -5°F to 122°F (-21°C to 50°C)
Heating Operation Range: -5°F to 75°F (-21°C to 24°C)

Warranty

7 Year Compressor, 5 Year Parts out-of-the-box Warranty.

10 Year Compressor, 10 Year Parts Warranty when registered within 60 days of installation in a residence.

12 Year Compressor, 12 Year Parts Warranty when registered within 60 days of installation in a residence and installed by a Fujitsu Elite contractor.

Dimensions

9,000 BTU/h & 12,000 BTU/h & 15,000 BTU/h

KUBS1G Technical Information

Select an individual KUBS1G unit below to view its compatibility with other products, and links to submittals and other data.

AGUH09KUAS 9,000 BTU/h 0.75-Ton Floor-Mounted Indoor Unit

AGUH12KUAS 12,000 BTU/h 1-Ton Floor-Mounted Indoor Unit

AGUH15KUAS 15,000 BTU/h 1.25-Ton Floor-Mounted Indoor Unit

Optional Accessories

KAGAMI Touch Panel Wired Controller (UTY-RVRU)*

Touch Panel Wired Remote Controller (UTY-RNRU Series)

Wi-Fi Adapter (WiFi Interface Module USB Type)

Intesis IR Wireless AC Cloud Control Interface (Intesis Home app)

*: Requires Communication kit UTY-TWRXZ2 to connect this device to Indoor Unit.

*: "AIRSTAGE" is a trademark of GENERAL Inc.
*: "STHP" is a trademark of GENERAL Inc.
