AIRSTAGE SINGLE ROOM MINI-SPLIT SYSTEM Standard-Tier Wall-Mounted Indoor Unit
AIRSTAGE Altair 300
KNAS1
Discover comfort and efficiency with the Altair 300 Series inverter heat pump. Designed for everyday needs, this wall-mounted system combines compact functionality with advanced fan technology for consistent performance and quiet operation. The slim outdoor unit and extended line set lengths allow for easy and versatile installation in a variety of spaces.
115V Size (kBTU/h): 9, 12 208-230V Size (kBTU/h): 9, 12, 15, 18, 24
Features
Ductless Technology
AIRSTAGE mini-splits are easy to install, require little or no ducting, and can provide comfort for any room or the entire home.
Year-Round Comfort
AIRSTAGE systems offer both heating and cooling to keep you comfortable year-round.
Energy Efficient
Save up to 30% on energy bills with AIRSTAGE H-Series systems. Take advantage of local rebates and save even more.
No Temperature Lockout!
Heating down to 5°F (-15°C) without sacrificing heating capacity at low outdoor temperatures
Ductless Technology
AIRSTAGE mini-splits are easy to install, require little or no ducting, and can provide comfort for any room or the entire home.
Year-Round Comfort
AIRSTAGE systems offer both heating and cooling to keep you comfortable year-round.
Energy Efficient
Save up to 30% on energy bills with AIRSTAGE H-Series systems. Take advantage of local rebates and save even more.
No Temperature Lockout!
Heating down to 5°F (-15°C) without sacrificing heating capacity at low outdoor temperatures
Specifications
- Sound Level: As low as 20dB
- SEER2: As high as 17.0 BTU/hW
- HSPF2: As high as 9.0 BTU/hW
- Energy Star: No
- Cooling Operating Range: 50°F to 126°F (10°C to 52°C)
- Heating Operation Range: 5°F to 75°F (-15°C to 24°C)
- Sound Level: As low as 20dB
- SEER2: As high as 20.0 BTU/hW
- HSPF2: As high as 9.0 BTU/hW
- Energy Star: Only on 18KNAS1 - 230V
- Cooling Operating Range: 50°F to 122°F (10°C to 50°C)
- Heating Operation Range: 5°F to 75°F (-15°C to 24°C)
Warranty
7 Year Compressor, 5 Year Parts out-of-the-box Warranty.
10 Year Compressor, 10 Year Parts Warranty when registered within 60 days of installation in a residence.
12 Year Compressor, 12 Year Parts Warranty when registered within 60 days of installation in a residence and installed by a Fujitsu Elite contractor.
7 Year Compressor, 5 Year Parts out-of-the-box Warranty.
10 Year Compressor, 10 Year Parts Warranty when registered within 60 days of installation in a residence.
12 Year Compressor, 12 Year Parts Warranty when registered within 60 days of installation in a residence and installed by a Fujitsu Elite contractor.
Dimensions
9,000 BTU/h
12,000 BTU/h
9,000 BTU/h & 12,000 BTU/h
18,000 BTU/h
24,000 BTU/h
Features
AIRSTAGE mini-splits are easy to install, require little or no ducting, and can provide comfort for any room or the entire home.
Optional Accessories
Wi-Fi Adapter (WiFi Interface Module USB Type)
Intesis IR Wireless AC Cloud Control Interface (Intesis Home app)
- *
- "AIRSTAGE" is a trademark of GENERAL Inc.
